Digital Force Gauge 100 x 0.1 lbf - DFE2-100
DFE2-100
New
The Chatillon® DFE II Series marks a new era in digital force measurement. This compact, easy-to-use force gauge is designed for economy applications without compromising functionality. Ideal for hand held or test stand applications. The DFE II Series is available with capacities from 2 lbf (10 N) to 500 lbf (2500 N).
Data sheet
| Weight | 4 Lbs / 2 kg |
| Power | Battery (Nickel Metal Hydride) or direct AC 120/230Vac |
More info
| Certification | NIST Certificate of Calibration with data | ||||||
|---|---|---|---|---|---|---|---|
| Accuracy: | +0.25% of Full Scale | ||||||
| Maximum Overload | 150% of Rated Capacity | ||||||
| Tare Capacity | 10% of Rated Capacity | ||||||
| Resolution: | 1000:1 | ||||||
| Peak Capture Rate | 7000 Hz | ||||||
| Data Sampling | 7 KHz | ||||||
| Display Update Rate | 10 Hz | ||||||
| Data Save | Up to 20 Results | ||||||
| Power | Battery (Nickel Metal Hydride) or direct AC 120/230Vac | ||||||
| Battery Life | With dimming ON: 20 Hours - With dimming OFF: 16 Hours | ||||||
| Operating Temperature | 40°F to 110°F (5°C to 45°C) | ||||||
| Outputs | RS232 , USB and +2V analog output | ||||||
| Multiple Language Interfaces | English, Spanish, French, German, Portuguese and Chinese | ||||||
| Instrument Weight | 1.5 lbs (0.7 kg) | ||||||
| Shipping Weight: | 4 lbs (2 kg) | ||||||
