AST3011 TRI-ROLLER PORTABLE TOOL FOR MS14101-9

The AST3011 is a genuine Aero Staking product designed to meet the highest standards for bearing installation and bearing retention in aerospace applications. This portable tri-roller swaging tool meets key industry specifications such as BAC5435, NAS0331 Method 200, BPS4162, PS17031, CSMP023, SS8743, FH-19, and 03-03-012, ensuring superior quality and performance.

Tool Compatibility & Specifications

• For Bearing Number: MS14101-9

• Bearing Groove Pitch Diameter (PD): 0.970

• Bearing Inner Diameter (ID): 0.5625

• Standard Outer Envelope of Tool: Diameter 1.500” OD

Tool Components and Features

• Flat-Surfaced Locating Fixture (Primary): Used for the first swage

• Angled (Conical) Locating Fixture (Secondary): Used for the second swage

• Roller Swaging Fixture (Head)

Perfect for On-Wing Applications

The AST3011 portable tri-roller bearing swaging tool is engineered for on-wing repairs, easily fitting into tight or constrained spaces. It is ideal for bearing retention, installation, and bearing replacement operations on aircraft, making it an essential tool for aerospace professionals working on-site or in restricted areas.

Lightweight, Mobile, and Easy to Maintain

• No power tools required

• Portable and lightweight for ease of use

• Durable and easy to maintain, with no weak links

Equipment Required: NO POWER TOOL NEEDED

This manual, lightweight tool is designed for efficient operation with no need for external power equipment, ensuring quick and effective bearing installation and retention in challenging environments.
