TB-9267-A220-ASL TOWBAR ASSEMBLY, A220 WITH 1.5" DIA NLG HOOK UP
TB-9267-A220-ASL
New
P & AUTO SAFETY LATCH
Data sheet
| Height | 27" |
| Width | 19.625" |
| Length | 180.375" |
| Weight | 208 LBS |
| Applicability Aircraft / Engines | A220 WITH 1.5" DIA NOSE PIN |
More info
NO SOFT START
NO HYD. LIFT
SHEAR PIN P/N TB-A220-SP
| OTHER CONFIGURATION | SHEAR PIN | LATCH TYPE | SOFT START | HYD. LIFT | NOSE PIN | |
| TB-9267-A220-ASL-SS | TB-A220-SP | AUTO SAFETY LATCH | YES | NO | 1.5" | |
| TB-9267-A220-ASL-HL | TB-A220-SP | AUTO SAFETY LATCH | NO | YES | 1.5" | |
| TB-9267-A220-ASL-HL-SS | TB-A220-SP | AUTO SAFETY LATCH | YES | NO | 1.5" | |
| TB-9267-A220-WL | TB-A220-SP | LHA (1/4") PIN | NO | NO | 1.5" | |
| TB-9267-A220-WL-SS | TB-A220-SP | LHA (1/4") PIN | YES | NO | 1.5" | |
| TB-9267-A220-WL-HL | TB-A220-SP | LHA (1/4") PIN | NO | YES | 1.5" | |
