TB-9267-ASL TOWBAR ASSEMBLY, B737-300 TO -900
TB-9267-ASL
New
TOWBAR ASSEMBLY, B737-300 TO -900 WITH AUTO SAFETY LATCH
Data sheet
| Height | 27" |
| Width | 19.625" |
| Length | 180.375" |
| Weight | 208 LBS |
| Applicability Aircraft / Engines | B737-300 TO -900 |
More info
NO SOFT START
NO HYD. LIFT
SHEAR PIN P/N TB-8312-B6
| OTHER CONFIGURATION | SHEAR PIN | LATCH TYPE | SOFT START | HYD. LIFT | NOSE PIN | |
| TB-9267-ASL-FA | TB-8312-B6 | AUTO SAFETY LATCH | NO | NO | 3/4" | |
| TB-9267-ASL-HL | TB-8312-B6 | AUTO SAFETY LATCH | NO | YES | 3/4" | |
| TB-9267-ASL-SS | TB-8312-BL | AUTO SAFETY LATCH | YES | NO | 3/4" | |
| TB-9267-ASL-HL-SS | TB-8312-BL | AUTO SAFETY LATCH | YES | YES | 3/4" | |
| TB-9267-ASL-S | TB-8312-B6-S | AUTO SAFETY LATCH | NO | NO | 3/4" | |
| TB-9267-ASL-S-HL | TB-8312-B6-S | AUTO SAFETY LATCH | NO | YES | 3/4" | |
| TB-9267-ASL-S-SS | TB-8312-B6-S | AUTO SAFETY LATCH | YES | NO | 3/4" | |
| TB-9267-S-HL-SS | TB-8312-B6-S | AUTO SAFETY LATCH | YES | YES | 3/4" | |
| TB-9267-WJ-ASL | TB-8312-B6-WJ | AUTO SAFETY LATCH | NO | NO | 3/4" | |
| TB-9267-WJ-ASL-HL | TB-8312-B6-WJ | AUTO SAFETY LATCH | NO | YES | 3/4" | |
| TB-9267-WJ-ASL-SS | TB-8312-B6-WJ | AUTO SAFETY LATCH | YES | NO | 3/4" | |
| TB-9267-WJ-ASL-HL-SS | TB-8312-B6-WJ | AUTO SAFETY LATCH | YES | YES | 3/4" |
ALSO AVAILABLE WITH LHA (1/4" DIA PIN) LATCH TYPE.
