FISHPOLE HOIST - HEAVY WEIGHT - PF51-009-1

FISHPOLE POWERED HOIST - HEAVY WEIGHT - PF51-009-1

Reference: PF51-009-1

Condition: New

FISHPOLE HOIST - HEAVY WEIGHT - PF51-009-1

Send to a friend

Send to a friend

FISHPOLE POWERED HOIST - HEAVY WEIGHT - PF51-009-1

FISHPOLE HOIST - HEAVY WEIGHT - PF51-009-1

Recipient :

Name of your friend ^* :

E-mail address of your friend ^* :

^* Required fields

or Cancel
Print

Data sheet

Weight	27 lbs.
Capacity	500 lbs.

More info

Powered versions of our standard manual hoists. Each model is lightweight and rated for a capacity of 500 lb. Equipped with telescoping barrel (5-9 ft.) and universal attach configuration. Select models include an integrated load limiter device that locks the winch when maximum set loads are exceeded.

Cable: 7 x 19 aircraft cable, 5/32 in. (4.0 mm) diameter, 40 ft. (12.2 m) length

Gear Ratio: 30:1

Drum-Loc Clutch: Enables rapid payout of slack cable (1:1 ratio). Positively locks if any load is on the cable.

Overload Device (on select models): Adjustable for hoist load limiting within a range of 100 to 500 lb., plus or minus 10%. Preset at factory to 500 lb.

Mode Selector Knob: Powered or manual mode may be selected while hoist cable is supporting a load.

Air Motor: 3/4 hp, 5.8 ft. per min. @ 90 psig
