FISHPOLE HOIST, MANUAL, 550 KG CAP / PF51-101-5A
PF51-101-5A
New
FISHPOLE HOIST, MANUAL, 550 KG CAP
Data sheet
| Weight | 28 lb. (12.7 kg) |
| Capacity | 1213 lb. (550 kg) |
More info
Designed specifically for Airbus aircraft and other heavy-load applications. Each hoist in our PF51-101 series is rated for a capacity of 550 kg and is built to accommodate a range of interchangeable barrel assemblies, allowing for tremendous flexibility between applications. Manual and powered models available.
| Cable: 7 x 19 aircraft cable, 3/16 in. (4.8 mm) diameter, 30 ft. (9.1 m) length |
| Gear Ratio: 76.4:1 (low speed); 40:1 (high speed) |
| Drum-loc Clutch: Enables rapid payout of slack cable (1:1 ratio). Positively locks if any load is on the cable. |
| Mode Selector Knob (powered models only): Powered or manual mode may be selected while hoist cable is supporting a load. |
| Air Motor (powered models only): 3/4 hp, 5.8 ft. per min. @ 90 psig |
