Waste Oil Drain 32 gal.
WOD-31XL
New
3-in-1 self-evacuating Waste Oil Drain (Model WOD-31XL) can be used to easily change the transmission and differential oil on most heavy-duty vehicles.
Data sheet
| Height | 60 in |
| Width | 26 |
| Weight | 184 lbs |
| Capacity | 32 gal. |
| Properties | Lowered Tray height 8.5 in |
More info
Draining Options
- By gravity, with tank on the floor.
- By gravity (pan raised), with vehicles placed on auto lift or over a pit.
- By suction, with probe inserted directly into the engine.
Features
- Easy to maneuver, simple to use.
- Large 13.5 gal. collection tray.
- Tank is equipped with fill sight tube.
- Suction probes included.
- No pump to wear out or maintain.
- A floating ball check-valve allows oil to enter, but seals the container for evacuation the moment air is connected.
Included Probes
- Probe 5mm dia. x 700mm flexable – part# 1845.1
- Probe 6mm dia. x 700mm flexable – part# 1845.2
- Probe 7mm dia. x 1,000mm flexable – part# 1845.3
- Probe 8mm dia. x 700mm flexable – part# 1845.4
- Probe 5mm dia. x 700mm moldable – part# 1845.5
- Probe 6mm dia. x 700mm moldable – part# 1845.6
Optional Probes
- Probe 7mm dia. x 1,900mm moldable – part# 1845.3A
