6021-5154 E20/20 TDR AVIONICS KIT COMPLETE
6021-5154
New
E20/20 TDR AVIONICS KIT COMPLETE
Data sheet
| Height | 6.9" |
| Width | 13.7" |
| Length | 18.1" |
| Weight | 11.5 lbs |
| Power | External Power: 90-240VAC 50/60Hz adapter to 15VDC |
| Applicability Aircraft / Engines | Boeing 737NG, Embraer Phenom |
More info
The TDR Avionics Kit is designed specifically for testing and fault locating on aircraft wiring. The Step TDR is ideal for troubleshooting all types of coax, twisted pairs, single-wires in a harness, and aircraft power cables. Use "Step TDR" technology's amazingly accurate display and locating ability to save time and money. The kit includes connection adapters for mating with aircraft wiring harness style connectors making testing fast and convenient. Additionally, the TDR, manuals, PC software and accessories are all in a rugged anti-FOD carrying case designed for flight line and aircraft use. ETDR PC Vision™ software can upload, save, and print test results, and customize the TDR's cable list for specific aircraft as desired. Designed specifically for aviation applications the Avionics TDR Complete Kit is contained in an ATA-3000 Class 1 carrying case.
*** The images shown on this page are for illustration purposes only and may not be an exact representation of the product ***
